5w-30w portable solar DC system, 40w-500w solar AC & DC systems, 600w-10kw solar off-grid systems . 10w-30w integrated solar led street light. solar mobile charger , solar torch,solar camping lamp.
2014年3月31日星期一
2014年3月27日星期四
5w-3AH portable solar home system, mini solar home generator
5w-3AH small portable DC solar home system
***spec: ***
1.5w poly solar panel ,with 5M long cable,size is 440*340*25mm
2.battery:3AH maintenance-free lead -acid battery .
3.controller panel is 5A
4.led lamp:3W/12v led LAMP with 3M cable ,switch,E27 holder.(optional)
5.cabinet: steel box ,with handle,size:220*115*180mm.
6.weight:3.7KG
7.package: cabinet box /28cm*20cm*25cm /1 carton/ 1pcs,solar panel/40cm*28cm*4cm/ 1 carton /1pcs.
8.warranty:5years
9.produce capacity:1000sets/month
10.payment terms:100% T/T
11.optional accessories:220v-15v/1A adapter,3w/12v led bulb lamp,1-10 mobile charge cable line,3w/12v mini usb fan.
***charge and discharge***
1.charging time:
solar panel:8-10hours.
main power :3-4hours.
2. discharging time:
for 3w/12v/ 1 pcs ,can use 4hours,at same time can use 3w USB fan 4hours, and charge mobile.
for 3w/12v/ 4 pcs ,can use 1.5hours,at same time can use 3w USB fan 1.5hours, and charge mobile
***picture***
2014年3月26日星期三
2600MA solar mobiler charger/enough power / 4 color/ gift carton package
***specs***
1,solar panel:0.4W thin film
2,Specification: 120 * 73 * 10 mm
3,Capacity:2600 MA
4,Input: DC 5 v 500 MA /output: USB1 5 v 400M A-800MA
5,Color: black, silver, red, blue
6,package size:165*115*52mm weight:295G
***function***
it can charge :
Mobile phone
The iphone
MP3
MP6
The PSP
A digital camera
***pictures***
1,solar panel:0.4W thin film
2,Specification: 120 * 73 * 10 mm
3,Capacity:2600 MA
4,Input: DC 5 v 500 MA /output: USB1 5 v 400M A-800MA
5,Color: black, silver, red, blue
6,package size:165*115*52mm weight:295G
***function***
it can charge :
Mobile phone
The iphone
MP3
MP6
The PSP
A digital camera
***pictures***
33AH-40AH solar AC&DC solar system cabinet box/ 500w sine wave inverter /5A control panel
***specs***
1.box shell: 1mm high-quality steel plate/1pcs
2.handle: high quality aluminum alloy /1 pcs
3.foot pad: wear-resisting rubber MATS/4pcs
4.output :USB port DC5V-5.5V /2pcs led lamp port DC 12V/8 PCS
5.input: solar DC 15-18V /1 pcs, main power : AC 220V-15V adapter /1 pcs
6.switch: light touch button switch/ 2 pcs
7.indicator :light charging indicator(red) over-current protection indicator(green)
8.control: circuit module low voltage protection,over current protection,short circuit protection
9.inverter:300w modify or pure sine wave solar inverter
10.controller:5A
11.size: 365*200*240mm(include handle height)
12.battery size(reference): 196*166*170mm/33AH-40AH include fixed card 1pcs
13.weight(KG) :net weight/9KG & grosss weight/ 12KG
14.warranty:5years
15.produce capacity: 1000sets/month.
***pictures***
2014年3月25日星期二
40w solar panels input /300w inverter output /solar system cabinet box
***specs***
1.box shell: 1mm high-quality steel plate/1pcs
2.handle: high quality aluminum alloy /1 pcs
3.foot pad: wear-resisting rubber MATS/4pcs
4.output :USB port DC5V-5.5V /2pcs led lamp port DC 12V/8 PCS
5.input: solar DC 15-18V /1 pcs, main power : AC 220V-15V adapter /1 pcs
6.switch: light touch button switch/ 2 pcs
7.indicator :light charging indicator(red) over-current protection indicator(green)
8.control: circuit module low voltage protection,over current protection,short circuit protection
9.inverter:300w modify or pure sine wave solar inverter
10.controller:5A
11.size: 315*155*240mm(include handle height)
12.battery size(reference): 196*131*172mm/17AH-24AH include fixed card 1pcs
13.weight(KG) :net weight/8KG & grosss weight/ 10KG
14.warranty:5years
15.produce capacity: 1000sets/month.
***pictures***
2014年3月22日星期六
120w-60AH solar off-grid systems
120w-60AH solar off-grid systems
120w-60AH small AC solar home system
***spec: ***
1.120w poly solar panel .
2.battery:60AH maintenance-free lead -acid battery .
3.controller panel is 5A
4.inverter: 300w pure sine wave solar inverter
5.led lamp:3W/12v led LAMP with 3M cable ,switch,E27 holder.(optional)
6.cabinet: steel box ,with handle,size:500*255*320mm.
7.weight:58KG
8.package: 55cm*32cm*38cm /1 carton/ 1pcs
9.warranty:5years
10.produce capacity:1000sets/month
11.payment terms:100% T/T
12.optional accessories:220v-15v adapter,3w led bulb lamp,10-1 mobile charge line,usb fan.
***charge and discharge***
1.charging time:
solar panel:8-10hours.
main power :3-4hours.
2. discharging time:
for 3w/12v/ 5 pcs ,can use 67hours.
for 220v ,75w TV ,can use 14 hours.
for 220v,75w tv ,15w fan, 50w computer , can use7 hours at same time.
***picture***
120w-60AH small AC solar home system
***spec: ***
1.120w poly solar panel .
2.battery:60AH maintenance-free lead -acid battery .
3.controller panel is 5A
4.inverter: 300w pure sine wave solar inverter
5.led lamp:3W/12v led LAMP with 3M cable ,switch,E27 holder.(optional)
6.cabinet: steel box ,with handle,size:500*255*320mm.
7.weight:58KG
8.package: 55cm*32cm*38cm /1 carton/ 1pcs
9.warranty:5years
10.produce capacity:1000sets/month
11.payment terms:100% T/T
12.optional accessories:220v-15v adapter,3w led bulb lamp,10-1 mobile charge line,usb fan.
***charge and discharge***
1.charging time:
solar panel:8-10hours.
main power :3-4hours.
2. discharging time:
for 3w/12v/ 5 pcs ,can use 67hours.
for 220v ,75w TV ,can use 14 hours.
for 220v,75w tv ,15w fan, 50w computer , can use7 hours at same time.
***picture***
80W-40ah AC&DC solar home system/ 500w ouput inverter solar systems
80w-40AH small AC solar home system
***spec: ***
1.80w poly solar panel .
2.battery:40AH maintenance-free lead -acid battery .
3.controller panel is 5A
4.inverter: 500w sine wave solar inverter
5.led lamp:3W/12v led LAMP with 3M cable ,switch,E27 holder.(optional)
6.cabinet: steel box ,with handle,size:365*200*240mm.
7.weight:45KG
8.package: 38cm*25cm*28cm /1 carton/ 1pcs
9.warranty:5years
10.produce capacity:1000sets/month
11.payment terms:100% T/T
12.optional accessories:220v-15v adapter,3w led bulb lamp,10-1 mobile charge line,usb fan.
***charge and discharge***
1.charging time:
solar panel:8-10hours.
main power :3-4hours.
2. discharging time:
for 3w/12v/ 5 pcs ,can use 22hours.
for 220v ,75w TV ,can use 4.5 hours.
for 220v,75w tv ,15w fan, 50w computer , can use 2.5 hours at same time.
***picture***
2014年3月20日星期四
15AH-17AH portable solar home system cabinet box /built in controller ,cable ,no battery/ have USB,LED LAMP output port
1.box shell: 1mm high-quality steel plate/1pcs2.handle: high quality aluminum alloy /1 pcs3.foot pad: wear-resisting rubber MATS/4pcs4.output :USB port DC5V-5.5V /2pcs led lamp port DC 12V/8PCS5.input: solar DC 15-18V /1 pcs, main power : AC 220V-15V /1 pcs6.switch: light touch button switch/ 2 pcs7.indicator :light charging indicator(red) over-current protection indicator(green)8.control: circuit module low voltage protection,over current protection,short circuit protection9.size: 220*115*240mm(include handle height) 10.battery size(reference): 181*76*167mm/15AH-17AH include fixed card 1pcs11.weight(KG) :net weight/1.55KG & grosss weight/ 1.8KG12.warranty:5years13.produce capacity: 1000sets/month.
2014年3月19日星期三
30w "all in one " solar led street light
Product model
|
ECS-YTH-30W
| |
Light source
|
LED 30W
| |
Solar panel
|
MONO 50W
| |
High capacity lithium battery
|
40AH
| |
Network power input
|
extensible
| |
The human body infrared sensor
|
Yes
| |
Overload protection
|
yes
| |
Size L*W*H(mm)
|
850*440*45
| |
lens
|
yes
| |
suttle weight(kg)
(kg)
|
10.5
| |
Luminous flux (lm)
|
Full power mode
|
3800-4800
|
Power saving mode
|
1950-2250
| |
Angle of induction
|
120
| |
Color temperature (K)
|
5000-6000
| |
Light sensor threshold (LX)
|
30
| |
Work time
|
Full power mode
|
≥15
|
Power saving mode
|
≥30
| |
Working temperature
|
Charging temperature
|
0℃—+70℃
|
Discharge temperature
|
-20℃—+70℃
| |
Storage temperature
|
-20℃—+45℃
| |
Degree of protection
|
≥IP65
| |
Suggest installation height range (m)
|
4—6
| |
Suggested that cloth lamp spacing range (m)
|
18—20
|
15w integrated solar led street light
Product model
|
ECS-YTH-15W
| |
Light source
|
LED 15W
| |
Solar panel
|
MONO 30W
| |
High capacity lithium battery
|
20AH
| |
Network power input
|
extensible
| |
The human body infrared sensor
|
Yes
| |
Overload protection
|
yes
| |
lens
|
yes
| |
Size L*W*H(mm)
|
800*320*45
| |
suttle weight(kg)
(kg)
|
6.8
| |
Luminous flux (lm)
|
Full power mode
|
1850-2400
|
Power saving mode
|
925-1075
| |
Angle of induction
|
120
| |
Color temperature (K)
|
5000-6000
| |
Light sensor threshold (LX)
|
30
| |
Work time
|
Full power mode
|
≥15
|
Power saving mode
|
≥30
| |
Working temperature
|
Charging temperature
|
0℃—+70℃
|
Discharge temperature
|
-20℃—+70℃
| |
Storage temperature
|
-20℃—+45℃
| |
Degree of protection
|
≥IP65
| |
Suggest installation height range (m)
|
4—5
| |
Suggested that cloth lamp spacing range (m)
|
13—18
|
